 Post subject: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 12:47 pm

Joined: Tue Sep 14, 2004 7:52 am
Posts: 1539
Location: Strasburg, PA
Prodded into action by Scranton Yard, here are some items from the shop.

Here are some recent photos showing where we stand on reassembling Rio Grande Southern #20. Our goal is to complete the major work on her this spring, and return her to Golden for CRRM to perform the final assembly (brake plumbing, painting, etc.).


Attachment:
20181217_143434.jpg [ 273.64 KiB | Viewed 2399 times ]

Here, Shelley is heating a rivet...

Attachment:
20181217_141030.jpg [ 175.39 KiB | Viewed 2399 times ]

...to rivet the smokebox door ring to the smokebox.

Attachment:
20190104_082516.jpg [ 304.98 KiB | Viewed 2399 times ]

Here, the smokebox is attached to the saddle. The boiler is in the background.

Attachment:
20190104_082445.jpg [ 279.62 KiB | Viewed 2399 times ]

New crosshead guides are made, and are being fitted in place.

Attachment:
20190104_082459.jpg [ 295.41 KiB | Viewed 2399 times ]

The valve gear is going back together. The main driving axle is new, as are the eccentrics. Way easier to work on without the boiler in the way.

Attachment:
20190104_082344.jpg [ 267.68 KiB | Viewed 2399 times ]

New valve stems are being made now.

Attachment:
20190104_082600.jpg [ 253.26 KiB | Viewed 2399 times ]

The slide valve seats have been lapped flat.

Attachment:
20190104_082412.jpg [ 341.89 KiB | Viewed 2399 times ]

The slide valve balance plates on the underside of the steam chest covers have been faced.

Attachment:
20190123_084109.jpg [ 281.23 KiB | Viewed 2399 times ]

Mike and Ben have started fitting #20's boiler to the frame and smoke box to help in setting up the new ash pan, furnace bearers, and waist sheets.

Attachment:
20190128_091302.jpg [ 273.75 KiB | Viewed 2399 times ]

In this shot, Casey is finishing #20's front furnace bearer in the "Mighty Mouse", our K&T #2 mill.

_________________
"It was not easy to convince Allnutt. All his shop training had given him a profound prejudice against inexact work, experimental work, hit-or-miss work."
C. S. Forester

Strasburg Rail Road Mechanical Department


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 1:02 pm

Joined: Wed Jul 18, 2018 3:31 pm
Posts: 34
Location: Kent Island, Maryland
I see a Tuckahoe Steam & Gas shirt! :) Looking great guys, keep up the good work.

_________________
Simon Miller
Queen Anne’s Railroad Society
New Blood


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 1:05 pm

Joined: Tue Sep 14, 2004 7:52 am
Posts: 1539
Location: Strasburg, PA
Attachment:
20190125_134740.jpg [ 286.58 KiB | Viewed 2349 times ]

Steamtown has hired us to build a new firebox for #3713. In this shot, the rear flue sheet has been flanged and had the flue holes water jet cut.

Attachment:
20181218_101327.jpg [ 246.84 KiB | Viewed 2349 times ]

Here are #3713's door sheet and crown sheet. We still have to form the door hole in the sheet. Steamtown is planning to layout and drill all of the staybolt and rivet holes.

Attachment:
20190111_143644.jpg [ 280.46 KiB | Viewed 2349 times ]

Our #89 is in the shop having lateral issues dealt with on her #3 driver. Here, new hub liners have been welded in place, and are cooling under the fiberglass blanket.

Attachment:
20181121_084725.jpg [ 299.34 KiB | Viewed 2349 times ]

Her tender is getting new wheel sets at the same time.

_________________
"It was not easy to convince Allnutt. All his shop training had given him a profound prejudice against inexact work, experimental work, hit-or-miss work."
C. S. Forester

Strasburg Rail Road Mechanical Department


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 1:12 pm

Joined: Tue Aug 02, 2005 1:25 pm
Posts: 5505
Kelly -

Fantastic work (as always!); thanks so much for the update.


Les


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 1:55 pm

Joined: Wed Jan 15, 2014 9:14 am
Posts: 227
I know I am not the only one to feel this way, but I have to say how much I appreciate and enjoy when you, and others, post these updates with detailed pictures. I am in a "dead zone" for locomotive restoration and never get to see this. The closest I come is the work that I do on my 2.5" scale 2-4-0. Which, by the way, some of the photos and info on this forum have helped along. Seeing parts set up during machining and assembly tells so much more of a story than just the finnished product. (It also raises many intriguing questions) It is nice to see how new parts are made and fit.
Thanks
E


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 2:35 pm

Joined: Wed Feb 24, 2010 8:21 pm
Posts: 378
Location: Danbury, CT
Good stuff! Thanks for sharing.

_________________
Randy Patterson
RMNE/NAUG


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 2:47 pm

Joined: Tue Jul 06, 2010 1:57 am
Posts: 188
Mr. Anderson,

Could you please explain the use of fiberglass on the weld of 89's #3 axle? I don't think I've ever seen that used before. Great post, as always!


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 3:20 pm

Joined: Thu Apr 14, 2005 9:34 pm
Posts: 2209
Location: Copenhagen, Denmark
Zak Lybrand wrote:
Mr. Anderson,

Could you please explain the use of fiberglass on the weld of 89's #3 axle? I don't think I've ever seen that used before. Great post, as always!


I believe it is to control the rate of cooling, so things don't go "click--KRACK".

_________________
Steven Harrod
Lektor
Danmarks Tekniske Universitet
Institut for Systemer, Produktion, og Ledelse


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 3:36 pm

Joined: Sun Aug 22, 2004 7:19 am
Posts: 5597
Location: southeastern USA
I'm interested in the whole procedure of welding in hub liners. I have built up hubs with wire welding using aluminum or silicon bronze wires before - a time and material consuming method. If the wheel centers are cast iron, and the liners are steel, presumably securing them with weld could be an interesting proposition using either Nirod or Eutectic...…. what works best for you guys?

_________________
Santayana: "He who does not remember the past is condemned to repeat it."
Corollary: "He who does is doomed to watch those who don't repeat it anyway."


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 4:02 pm

Joined: Thu Feb 27, 2014 10:08 am
Posts: 429
Kelly Anderson wrote:
Here are #3713's door sheet and crown sheet. We still have to form the door hole in the sheet. Steamtown is planning to layout and drill all of the staybolt and rivet holes.


Thanks for taking the time to post. Glad to see work on 3713 is coming along. Bruce Mowbray has really turned that project around. Its a credit to him persevering in being heard and to Debbie Conway for hearing what he had to say. Once formed, is the firebox going back to STEA as individual sheets or is Strasburg welding it up? Having STEA layout and drill the staybolt holes is a good way to avoid the misalignment issues (between the inner and outer sheets) with the second firebox that we discussed in the 3713 thread a few years back. Have they done the Form 4 on their staybolt layout or is Strasburg responsible for that?

Has anything been done with the box car and flat car that you posted about back in May?

Are the hub liners on 89 steel or cast iron?


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 4:44 pm

Joined: Thu May 06, 2010 10:30 pm
Posts: 684
Location: Bucks County, PA
Correct me if I'm wrong, but is that a saddletanker back behind the tender? If so, which one?

_________________
Big Jim Video Productions
Morrisville, PA

http://www.bigjimvideo.com/home.html
http://www.youtube.com/user/bigjim4life


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Wed Jan 30, 2019 7:51 pm

Joined: Fri Aug 27, 2004 7:57 am
Posts: 2392
Location: Faulkland, Delaware
The saddle tanker is former Sugar Pine Lumber #37 that was formerly at W&W.

_________________
Tom Gears
Wilmington, DE

If you can't fix it with a hammer, you've got an electrical problem.


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Fri Feb 01, 2019 12:03 am

Joined: Sun Aug 22, 2004 7:07 am
Posts: 703
Location: Philadelphia Pa
tomgears wrote:
The saddle tanker is former Sugar Pine Lumber #37 that was formerly at W&W.


Poor thing is 95 years old and has spent nearly 30 years as a hanger queen/project.

Deserves a better fate and could have had it had cooler heads prevailed.

At least there is a plan


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Fri Feb 01, 2019 9:27 am

Joined: Sun Aug 22, 2004 11:26 am
Posts: 4032
Location: Maine
Kelly, I'm delighted to see your involvement with 3713. CNR 89 is an old friend. Glad to see her getting a complete health check as well.

_________________
"It's only impossible until it's done." -Nelson Mandela


Offline
 Profile

 Post subject: Re: The Latest from the Strasburg Rail Road Shops
PostPosted: Fri Feb 01, 2019 10:23 am

Joined: Mon Oct 01, 2018 3:51 pm
Posts: 40
Location: Ipswich, Mass., Phoenix, AZ
I'll join the others in a big "thanks for posting"! Your posts are some of the many highlights of this site.
Ned
