 Post subject: Locust Summit hopper W/archbar roller trucks
PostPosted: Tue Feb 19, 2019 9:32 am

Joined: Wed Apr 24, 2013 10:17 pm
Posts: 91
Gentlemen,

These photos were posted on the FOTRR Facebook group yesterday detailing a hopper car that has seen better days. The highlight of the pictures shows archbar roller bearing trucks. Archbars are rare in general, but I believe this is the first set I've seen with rollers. If anyone would think it would be worthwhile, the car is sitting off rails in the dirt. The frame is broken and body destroyed, but without further inspection, I'd say the trucks look OK.


As for ownership, I'd assume the property owner at the old breaker has it. I do not have contact info on that.

- Christian B.


Attachments:
FB_IMG_1550582621429.jpg [ 83.86 KiB | Viewed 2962 times ]
FB_IMG_1550582616947.jpg [ 87.39 KiB | Viewed 2962 times ]

_________________
http://www.strasburgrailroad.com
Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Tue Feb 19, 2019 10:58 am

Joined: Sun Sep 14, 2014 5:05 pm
Posts: 870
What is FOTRR and where is the car located? C. M. Lovestead of Seattle, WA supplied a lot of roller bearing conversions for archbar trucks to the sugar industry and other industrial railroads.


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Tue Feb 19, 2019 11:00 am

Joined: Mon Aug 23, 2004 8:10 am
Posts: 2433
The coal land at Locust Summit, PA is owned by Reading Anthracite. The company has a few rusty treasures accessible on its lands and also stashed away. Areas not being actively mined are open for public access permits. Areas being mined or reclaimed are entirely off limits w/o company permission. For those who want to explore legally: https://readingoutdoors.com/trails-parking-entry-maps

_________________
Rob


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Tue Feb 19, 2019 3:18 pm

Joined: Sun Sep 14, 2014 5:05 pm
Posts: 870
Here are a couple of other examples:

One from Japan
https://en.wikipedia.org/wiki/Bogie#/me ... -Truck.jpg

Nevada Northern wrecker
https://model-railroad-hobbyist.com/node/32090?page=1


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Tue Feb 19, 2019 4:21 pm

Joined: Tue Sep 14, 2004 7:52 am
Posts: 1674
Location: Strasburg, PA
Those look similar to the 1915 "Roll Way" roller bearings on our LO&S #10.

Attachment:
small 20190219_131608.jpg
small 20190219_131608.jpg [ 333.61 KiB | Viewed 2569 times ]


Attachment:
small old.jpg
small old.jpg [ 306.33 KiB | Viewed 2569 times ]

_________________
"It was not easy to convince Allnutt. All his shop training had given him a profound prejudice against inexact work, experimental work, hit-or-miss work."
C. S. Forester

Strasburg Rail Road Mechanical Department


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Tue Feb 19, 2019 4:23 pm

Joined: Fri Jun 01, 2018 12:05 pm
Posts: 74
John T wrote:
What is FOTRR and where is the car located?


I wonder if the OP meant AOTT (Ahead Of The Torch), not FOTRR? A post on this particular hopper was posted to AOTT yesterday by a Steven Zuby and I have linked his original post here:

https://www.facebook.com/steven.zuby/posts/2141340775917702

I did not need to sign into Facebook to view the 12 photos posted. Looks like the OP of this thread copied two of the images from Mr. Zuby's post in this thread.

Location? Mr. Zuby says it is Locust Summit which is in Pennsylvania. Hopper is at the site of a old coal breaker there.


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Tue Feb 19, 2019 5:48 pm

Joined: Mon Aug 23, 2004 5:10 pm
Posts: 1023
The coal processing facility at Locust Summit was built by a predecessor of the Reading Anthracite Company in the early 1930's. It was at that time the largest such facility in the world. There was a fleet of these hopper cars that were used to haul rock and culm out to the dumps. Much of that end of the property was electrified, and there were three 250vdc 6-wheel steeple cab Baldwin-Westinghouse locomotives that also had batteries to run out from under the wire on the temporary track on the dump. Locust Summit was also the home of former CNJ 0-6-0 No. 113 from around 1952 until the plant was closed in the early 1960's. The breaker was razed about two years ago, and the site is now being mined for coal spoil on the ground. The idea of a central breaker was that coal was collected from mines throughout the region and delivered here by the trainload for processing. It was then reloaded into hopper cars for movement to market.


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Wed Feb 20, 2019 12:27 pm

Joined: Wed Apr 24, 2013 10:17 pm
Posts: 91
Robert J wrote:
John T wrote:
What is FOTRR and where is the car located?


I wonder if the OP meant AOTT (Ahead Of The Torch), not FOTRR? A post on this particular hopper was posted to AOTT yesterday by a Steven Zuby and I have linked his original post here:

https://www.facebook.com/steven.zuby/posts/2141340775917702

I did not need to sign into Facebook to view the 12 photos posted. Looks like the OP of this thread copied two of the images from Mr. Zuby's post in this thread.

Location? Mr. Zuby says it is Locust Summit which is in Pennsylvania. Hopper is at the site of a old coal breaker there.

I believe it was posted in multiple groups. The friends of the Reading Railroad group is where it originated from.

_________________
http://www.strasburgrailroad.com


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Fri Feb 22, 2019 1:49 pm

Joined: Tue Aug 24, 2004 3:07 pm
Posts: 676
One of the early applications of roller bearings was on cars that dealt with high temperatures, such as hot metal cars and slag thimbles. The heat would cook the oil and journal pads of plain bearings whereas the rollers could be packed with high temperature grease and remain unaffected.


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Sat Feb 23, 2019 12:35 am

Joined: Fri Dec 22, 2017 6:47 pm
Posts: 184
Location: Philadelphia, PA
Dave's post makes sense. However, the anthracite breakers did not heat the coal to high temperatures.

Philadelphia and Reading Coal and Iron (C&I) had built two modern central breakers, one at Locust Summit and a second at St. Nicholas, both on Reading Company's Mahanoy and Shamokin Branch and both opened in 1930-1931. Both of these breakers have been demolished.

To fill in some blank spots, anthracite requires more processing than bituminous coal. In addition to picking the slate and other impurities, anthracite is sorted on size. This is done at a breaker and in later days, raw coal was moved from the colliery (mine) to a central breaker for processing.

In this case C&I built the two breakers to handle all the coal in that area. Locust Summit closed in 1955, old St. Nick in 1965. C&I, renamed Reading Anthracite Co., built a new St. Nicholas breaker near Minersville, outside Pottsville and on the other side of Broad Mountain. New St. Nick is currently operating and rail service is by RBMN.

The electric locomotives were three-axle standard gauge C (0-6-0) with pantographs and a steam-type outside frame, center cab and a short steeple on either side. I never saw them in operation but I might speculate if the culm cars had been a gravity return (like a McMyler dumper), the roller bearings would have helped with the return. Plus they were sealed in a gritty environment. The last two sentences are pure speculation.

Phil Mulligan


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Sat Feb 23, 2019 9:27 am

Joined: Tue Aug 24, 2004 3:07 pm
Posts: 676
As if to amplify Phil's comment about roller bearings vs. gritty environments, I recall the first group of freight cars on which PRR invested in roller bearings was an order of shorty covered hoppers for the cement and lime trade. These appeared around 1957 with the older design Timken journals with non-rotating covers.


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Sat Feb 23, 2019 9:40 pm

Joined: Wed Dec 24, 2014 3:15 pm
Posts: 176
Wasn’t CNJ 113 rescued from locust summit after rusting there for a number of years? Or was it somewhere else.


Offline
 Profile

 Post subject: Re: Locust Summit hopper W/archbar roller trucks
PostPosted: Sat Feb 23, 2019 10:13 pm

Joined: Wed Jan 11, 2017 5:54 pm
Posts: 70
Steamguy73 wrote:
Wasn’t CNJ 113 rescued from locust summit after rusting there for a number of years? Or was it somewhere else.

Read the above post by G. W. Laepple.
